HP-S04 Full Electric Hospital Bed with Perforated Deck
Price, lead time and documents for your market are confirmed in the quotation.
Key takeaways
- Five electric functions with a long-hole (perforated) deck, both named in the model.
- The product image shows bar-type side rails, an IV pole and a crank handle at the foot end; their specification is confirmed with the quote.
- Choose HP-S04 for an open-frame five-function bed, or HP-S03 if you prefer split side rails with built-in controls.
The HP-S04 full electric hospital bed runs its five functions from an electric drive and combines them with a long-hole (perforated) deck, both named in the model. Perforated deck panels let air circulate under the mattress. The bed suits hospitals and distributors that want five-function positioning on a simple, open frame.
Key Features
- Five electric functions. The image lists back lifting, knee lifting, back and knee, forward tilting, backward tilting and integral lift.
- Long-hole perforated deck sections.
- Bar-type side rails and an IV pole, as shown on the product image; rail material is confirmed on the specification sheet.
- A crank handle is visible at the foot end. Ask us to confirm its function for this model.
Applications
- General wards that need tilt positions on an open-frame bed.
- Nursing homes and rehabilitation units with higher-dependency residents.
- Distributor stock where one five-function model must serve many buyers.
How to specify when requesting a quote
- Quantity and destination.
- Mains voltage and plug type.
- Whether the IV pole and side rails shown are required in your configuration.
- Mattress thickness and cover, sized to the deck on the specification sheet.
- Documents your importer or tender requires.
Specifications
| Model | HP-S04 |
|---|---|
| Bed type | Electric hospital bed |
| Number of electric functions | 5 |
| Deck type | Long-hole (perforated) deck |
| Movements marked on product image | Back lifting; knee lifting; back and knee lifting; forward tilting; backward tilting; integral lift |
| Side rails (as shown on product image) | Bar-type side rails |
| Accessories shown on product image | IV pole |
Documents
Certificates, declarations of conformity and test reports for the specific model and destination market are provided with the quotation.
Tell us the destination country and the documents your import license, registration or tender requires. The specification sheet and user instructions are matched to the configuration you order, including the control-box voltage and plug type.
Frequently asked questions
+What is a full electric hospital bed?
A full electric bed adjusts every movement with motors, including overall height. A semi-electric bed powers the back and knee sections but raises and lowers the whole bed with a hand crank. Full electric beds reduce manual handling for caregivers.
+What does a long-hole (perforated) deck do?
Perforated deck panels let air circulate under the mattress and let moisture escape, and they weigh less than a solid board of the same size. Pair the deck with a mattress sized to the deck dimensions on the specification sheet.
+How is the HP-S04 different from the HP-S03?
Both are five-function electric beds. The HP-S04 has a long-hole perforated deck and bar-type side rails with an IV pole shown; the HP-S03 has split side rails with control keys built into the head-end rail.
+Is the HP-S04 suitable for home care?
It can be used at home where there is space and a suitable power outlet, but many home-care buyers choose a three-function bed. See the HP-S07 electric hospital bed for home use.
